VITS60M

SKU640891232
Manufacturer/ModelTest Kits
Weight (lbs)23
Dimensions (in)16.9 x 14 x 8

Product Description

The VITS60M vacuum interrupter integrity tester (aka vacuum bottle integrity tester) from Vacuum Interrupters is a user-friendly, portable, and lightweight tester that includes everything required to test the integrity of vacuum interrupters in the field or shop. The 60kV test set incorporates a variable high-voltage power supply, back-lit LCD display, comprehensive safety features, and is furnished with a complete set of test cables.  The 3-in-1 test set has superior performance as a 2.5/5/10kV megohmmeter and can function as a stand-alone 60kV DC HiPot. When used as a megohmmeter, the tester not only measure insulation resistance, but provides automated test routines for polarity index and absorption rate tests. The unit includes safety features such as auto-discharging, interlock, and a safety control button, a tough dual-case design, and an optional five-year warranty with loaner service included. Never be down more than a day.
